MG54248 [마그네트론] MG5424 — X-BAND 레이더용 25kW 안녕하세요 얼라이드이파트입니다! 장비 점검 나가기 전에 “오늘도 전파 잘 나가려나?” 하며 하늘 한번 쳐다본 적 있으신가요? 레이더가 세상을 보는 ‘눈’이라면, 그 눈에 생명을 불어넣는 건 바로 마그네트론입니다. 오늘은 X-밴드 레이더의 핵심인 MG5424에 대해 이야기해보려 합니다. 이 제품은 X-밴드 레이더 시스템용으로 설계된, 고출력 펄스형 마그네트론으로서, 고주파(약 9.41 GHz)에서 최대 약 25 kW 피크 출력을 내며 안정적인 레이더 신호 송출을 가능하게 해줍니다. 구분세부 내용동작 주파수9,410 MHz ± 30 MHz (X-밴드)출력 성능피크 출력 25 kW / 평균 출력 18 W히터 전압권장 6.3 V히터 전류0.5 A ~ 0.6 A (6.3 V 기준)예열 시간최소 60초 (0.. 2025. 10. 28. E2V Magnetron List Part No. Frequency (MHz) Peak Power (kW) Peak Anode Voltage (kV) Peak Anode Current (A) MG5315 3040 - 3060 12 5.8 5 MG5223F 3040 - 3060 30 8 8 MG5267 3025 - 3075 56 9 15 MG5240 3025 - 3075 60 9.3 15 MG5353 9380 - 9440 1.5 2 2 MG4004 9380 - 9440 4 3.7 3 MG5328A 9415 - 9475 4 3.7 3 MG5238B 9415 - 9475 4 3.7 3 MG5243 9415 - 9475 4 3.7 3 MG5248 9380 - 9440 4 3.7 3 MG5251 9380 - 9440 4 3.7 3 MG5388 9.. 2012. 6. 28. MG5424 X-Band Magnetron GENERAL DATA Electrical Mechanical Operating frequency 9410 ±30 MHz Overall dimensions see Outline Typical peak output power 25 kW Net weight 0.7 kg approx Cathode indirectly heated Mounting position any Heater voltage (see note 1) 6.3 V Coupler IEC UBR100 Heater current at 6.3V (see note 2) 0.5 A Cooling natural Cathode pre-heating time (minimum) (see note3) 60 s Output no.16 waveguide (22.86 *.. 2012. 6. 28. RF Receivers Parts List(RF 리시버) E2V Part No. Frequency (MHz) MDS (dBm typical) Noise figure (dB max) Power supplies B3IM16161 9.3 - 9.5 -100 4.7 +15, +5, -15 4 bandwidths, perfomance monitoring, AFC B3IM16171 9.1 - 9.3 -100 4.7 +15, +5, -5.2 Frequency variant of B3IM1616 2011. 8. 16. Noise generators Parts List(노이즈 제너레이터) E2V Part No. Frequency (MHz) ENR (dB max) Incident power pulsed, 1µs (kW max) Power supplies B3NG1639 8.8 - 9 15 60 +21 V, 0 - 25 mA Waveguide (WG16) cal. frequency 8900 GHz B3NG1641 9.3 - 9.5 15 60 +21 V, 0 - 25 mA Waveguide (WG16), cal. frequency 9.375 GHz B3NG1642 9.3 - 9.5 15 60 +21 V, 0 - 25 mA Waveguide (WG16), cal. frequency 9.410 GHz B3NG1004 3000 - 3100 15 60 +24 V, 0 - 30 mA Waveguide .. 2011. 8. 16. Front ends Parts List(프론트엔드) E2V Part No. Frequency (MHz) Gain (dB min) Noise figure (dB max) Power supplies B7RX1001 3.02 - 3.08 6 3 +12 V, Vr 4 - 24 V IF output BNC female, filtered power supplies B7RX1002 3.02 - 3.08 6 3 +12 V, Vt 4-24 V Feedthrough pin connectors B7RX1008 3.02 - 3.08 6 3 +12 V, Vt 4-24 V IF output BNC female, RF input filter B3RX1612 9.3 - 9.5 2.5 3.5 +5 V, Vt 4-24 V PCB edge connector B3RX1613 9.36 - 9.. 2011. 8. 16. Circulators Parts List(서큘레이터) e2v technologies manufacture Ferrite Devices operation from 350 MHz to 120 GHz, for a wide variety of applications from low cost marine radar to state-of-the-art military devices. Standard units are available in regular waveguide sizes and some special sizes. e2v technologies offer circulators and isolators as stand-alone units and also as part of an integrated microwave package. They all come w.. 2011. 8. 16. Limiters Parts List(리미터) E2V Part No.Frequency (MHz)Peak Power(kW)STCAttenuation(dB)Length(mm)B3LT16129300 - 950010 35B3LT10083020 - 3080303055B3LT1014B3020 - 308030 112B3LT10143020 - 308030 74BS1693030 - 307025 32.9B6LT10693030 - 307025 32.9B3LT161048800 - 900030 44B3LT161248800 - 9000303044B3LT16109300 - 950010 35B3LT16689360 - 9460252535B3LT161149300 - 950050 60B3LT10183020 - 3080303055B3LT10233020 - 3080303055B3LT16.. 2011. 8. 16. 이전 1 다음
